ADLINK Express-CVC - Manual (Page 37)

Express-CVC Page 37
5.5. PCI Configuration Space Map
Bus
Number Device
Number Function
Number Routing Description
00h 00h 00h N/A Intel Host Processor Bridge
00h 02h 00h Internal Intel P.E.G. Root Port
00h 1Bh 00h Internal Intel HD Audio Device
00h 1Ch 00h Internal Intel PCI Express Root Ports 0
00h 1Ch 01h Internal Intel PCI Express Root Ports 1
00h 1Ch 02h Internal Intel PCI Express Root Ports 2
00h 1Ch 03h Internal Intel PCI Express Root Ports 3
00h 1Dh 00h Internal Intel USB UHCI Host Controllers 0
00h 1Dh 01h Internal Intel USB UHCI Host Controllers 1
00h 1Dh 02h Internal Intel USB UHCI Host Controllers 2
00h 1Dh 03h Internal Intel USB UHCI Host Controllers 3
00h 1Dh 07h Internal Intel USB EHCI Host Controller
00h 1Eh 00h N/A Intel PCI-to-PCI Bridge
00h 1Fh 00h N/A Intel LPC Interface Bridge
00h 1Fh 02h Internal Intel SATA controller
00h 1Fh 03h Internal Intel SMBus Controller
02h 00h 00h Internal Intel Ethernet Controller
