Page 10 Express-CVC
2.10. TPM (Trusted Platform Module)
¾ Chipset: Atmel AT97SC3204T, LPC type (optional)
¾ Type: TPM 1.2
2.11. Fan Control
¾ Control Source: Temperature Sensor
¾ Location : 4-pin Mini connector on module: 5V for smart fan
2.12. Power Specifications
¾ Power Modes: AT and ATX mode (AT mode controlled by SEMA BC)
¾ Wide Voltage Input: ATX mode : 5~20V & 5Vsb +/- 5% or AT mode : 5 ~20V
¾ Power Management: ACPI 3.0 compliant, Smart Battery support.
¾ Power States: supports C1-C6, S0, S1, S3, S4, S5
¾ S5 Eco Mode: minimal power during S5 (all wake-up functions disabled)
2.13. Mechanical and Environmental
¾ Standard Operating Temperature: 0 to 60°C
2.14. Specification Compliance
¾ PICMG COM.0: Rev 2.1 Type 2,
¾ Size : Compact size 95 x 95 mm
