Express-CVC Page 33
5. System Resources
5.1. System Memory Map
Address Range (decimal) Address Range (hex) Size Description
(4GB-2MB) FFE00000 – FFFFFFFF 2 MB High BIOS Area
(4GB-18MB) – (4GB-17MB-1) FEE00000 – FEEFFFFF 1 MB FSB Interrupt Memory Space
(4GB-20MB) – (4GB-19MB-1) FEC00000 – FECFFFFF 1 MB APIC Configuration Space
960 K – 1024 K F0000 – FFFFF 64 KB System BIOS Area
896 K – 960 K E0000 – EFFFF 64 KB Extended System BIOS Area
768 K – 896 K C0000 – DFFFF 128 KB Onboard VGA BIOS ROM
Intel i210 PXE ROM
640 K – 768 K A0000 – BFFFF 128 KB Legacy Video Buffer Area
0 K – 640 K 00000 – 9FFFF 640 KB DOS Area
5.2. Direct Memory Access Channels
Channel Number Data Width System Resource
0 8-bits Generic
1 8-bits Generic
2 8-bits Generic
3 8-bits Generic
4 Reserved - cascade channel
5 16-bits Generic
6 16-bits Generic
7 16-bits Generic
Note: These IRQs can be used for PCI devices when onboard device is disabled
