Page 60 Express-CVC
Terminal Type
VT100+ is the preferred terminal type for out-of-band management. Configuration options: VT100, VT100+, VT-UTF8 , ANSI.
Bits per second
Select the bits per second you want the serial port to use for console redirection. The options are 115200, 57600, 38400, 19200,
9600.
Data Bits
Select the data bits you want the serial port to use for console redirection. Set this value to 7 / 8.
Parity
Set this option to select Parity for console redirection. The settings for this value are None, Even, Odd, Mark, Space.
Stop Bits
Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit.
Communication with slow devices may require more than 1 stop bit. Set this value to 1 and 2.
Flow Control
Set this option to select Flow Control for console redirection.
The settings for this value are None, Hardware RTS/CTS.
VT-UTF8 Combo Key Support
Enable VT-UTF8 Combination Key Support for ANSI/VT100 terminals
Recorder Mode
Enabled this mode, only text will be sent. This is to capture terminal data. Set this value to Enabled/Disabled.
Resolution 100x31
Set this option to extended terminal resolution. Set this value to Enabled/Disabled.
Legacy OS Redirection
On Legacy OS, the number of rows and columns supported redirection.
Set this value to 80x24 / 80x25.
Putty KeyPad
Select Function Key and KeyPad on Putty.
Redirection After BIOS POST
The Settings specify if BootLoader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default
value is Always Enable which means Legaacy console Redirection is enabled for Legacy OS.
