Page 8 Express-CVC
2. Specifications
2.1. Core System
¾ CPU: Intel® Atom® Processor, 2-core with Integrated Graphics, FCBGA559 type
• Dual-Core Intel® Atom™ Processor N2600 1.66Gz (1MB L2 cache, 3.5W)
• Dual-Core Intel® Atom™ Processor N2800 1.86Gz (1MB L2 cache, 6.5W)
• Dual-Core Intel® Atom™ Processor D2550 1.86Gz (1MB L2 cache, 10W)
¾ Cache: 1MB to 16MB LLC cache depending on CPU type
¾ Memory: Single SODIMM socket supporting non-ECC DDR3 at 1066 MHz on N2800 and D2550 (max. 4 GB),
at 800 MHz on N2600 (max. 2GB)
¾ Chipset: Intel® NM10 Express Chipset
¾ BIOS: Dual BIOS AMI APTIO UEFI in 16 Mbit SPI flash
¾ Hardware Monitor: Supply voltages and CPU temperature
¾ Fan Control: mini connector on module
¾ Debug Interface: XDP SFF-26 extension for ICE debug
2.2. Expansion busses
¾ PCI Express Gen 1.0 Ports 4 x1 from PCH
(one lane occupied by GbE LAN controller)
Three free PCIe x 1 on AB port 0, 1 and 2
¾ LPC bus, SPI bus (BIOS only)
¾ SMBus (system) , I2C (user)
2.3. Video
¾ Integrated in Processor: Integrated PowerVR SGX 545 Graphics supporting dual independent displays
¾ Graphics Core Speed : 640 MHz (D2550 & N2800) and 400 MHz (N2600)
¾ Feature Support:
• 1080p HD Video
• Playback, Blu-ray 20
• DirectX 9
• MPEG2 hardware decode
¾ Multi Display Support: 2 independent displays
¾ Display Types
• VGA Interface support with 300 MHz DAC Analog monitor support up to QXGA (2048 x 1536)
• eDP/DP: converted to Dual channel 18/24-bit LVDS with Chrontel CH7511
• DP: connector on module type
