Page 8 Express-HL2
2.5 LAN
¾ Integrated: LAN MAC integrated in PCH QM87/HM86
¾ Intel PHY: Intel® Ethernet Controller i217LM
¾ Interface: 10/100/1000 GbE connection
2.6 Multi I/O and Storage
¾ Integrated in Intel® QM87/HM86 Express Chipset
¾ USB ports: 8 ports USB 2.0 (USB 0,1,2,3,4,5,6,7)
¾ SATA ports: four ports SATA 6Gb/s (SATA0, SATA1, SATA2, SATA3) – QM87
three ports SATA 6Gb/s (SATA0, SATA2, SATA3, no SATA1) – HM86
¾ PATA ports: one PATA IDE (through SATA to PATA bridge)
¾ GPIO: 4 GPO and 4 GPI with interrupt
2.7 TPM (Trusted Platform Module)
¾ Chipset: ATMEL AT97SC3204
¾ Type: TPM 1.2
2.8 SEMA Board Controller
¾ Type: ADLINK Smart Embedded Management Agent (SEMA)
¾ Supports:
• Voltage/Current monitoring
• Power sequence debug support
• AT/ATX mode control
• Logistics and forensic information
• Flat panel control
• General purpose I2C
• Failsafe BIOS (dual BIOS )
• Watchdog timer and fan control
2.9 Debug
¾ 40-pin flat cable connector to be used with DB-40 debug module
• Supports: BIOS POST code LEDs, BMC access, SPI BIOS flashing, power testpoints, debug LEDs
¾ 60-pin XDP header for ICE debug of CPU/chipset
