Page 16 Express-HL2
3.3 AB Signal Descriptions
3.3.1 Audio Signals
Signal Pin # Description I/O PU/PD Comment
AC_RST# /
HDA_RST# A30 Reset output to codec, active low. O 3.3VSB
AC_SYNC /
HDA_SYNC A29 Sample-synchronization signal to the codec(s). O 3.3V
AC_BITCLK /
HDA_BITCLK A32 Serial data clock generated by the external codec(s). I/O 3.3V
AC _SDOUT /
HDA_SDOUT A33 Serial TDM data output to the codec. O 3.3V
AC _SDIN[2:0]
HDA_SDIN[2:0] B28
B30 Serial TDM data inputs from up to 3 codecs. I/O 3.3V
3.3.2 Analog VGA
Signal Pin # Description I/O PU/PD Comment
VGA_RED B89 Red for monitor.
Analog DAC output, designed to drive a 37.5-Ohm
equivalent load. O Analog PD 150R Shall also be terminated on the
carrier with 150Ω resistor to
ground close to VGA connector
VGA_GRN B91 Green for monitor
Analog DAC output, designed to drive a 37.5-Ohm
equivalent load. O Analog PD 150R Shall also be terminated on the
carrier with 150Ω resistor to
ground close to VGA connector
VGA_BLU B92 Blue for monitor.
Analog DAC output, designed to drive a 37.5-Ohm
equivalent load. O Analog PD 150R Shall also be terminated on the
carrier with 150Ω resistor to
ground close to VGA connector
VGA_HSYNC B93 Horizontal sync output to VGA monitor O 3.3V
VGA_VSYNC B94 Vertical sync output to VGA monitor O 3.3V
VGA_I2C_CK B95 DDC clock line (I²C port dedicated to identify VGA
monitor capabilities) I/O OD 3.3V PU 2k2
3.3V
VGA_I2C_DAT B96 DDC data line. I/O OD 3.3V PU 2k2
3.3V
