Express-HL2 Page 67
7.3.13 Thermal
Feature Options Description
Thermal Info only
Automatic Thermal Reporting
Enabled
Disabled Configure _CRT, _PSV and _AC0 automatically based on values
recommended in BWG’s Thermal Reporting for Thermal
Management settings
. Set to Disabled for manual conmfiguration .
Critical Trip Point Disabled
85 C
95 C This value controls the temperature of the ACPI Critical Trip Point -
the point in which the OS will shut the system off
.
NOTE: 100C is the Plan Of Record (POR) for all Intel mobile
processors
.
Active Trip Point Disabled
40 C
50 C
60 C
70 C
BMC Default This value controls the temperature of the ACPI Active Trip Point -
the point in which the OS will turn the processor fan on Active Trip
Point Fan Speed
.
Passive Trip Point Disabled
80 C
90 C This value controls the temperature of the ACPI Passive Trip Point -
the point in which the OS will begin throttling the processor
.
Passive TC1 Value 1 This value sets the TC1 value for the ACPI Passive Cooling
Formula
. Range 1 – 16 .
Passive TC2 Value 5 This value value sets the TC2 value for the ACPI Passive Cooling
Formula
. Range 1 - 16
Passive TSP Value 10 This item sets the TSP value for the ACPI Passive Cooling Formula .
It represents in tenths of a second how often the OS will read the
temperature when passive cooling is enabled
. Range 2 – 32 .
Watchdog ACPI Even Shutdown Disabled
Enable Enable/Disable Watchdog ACPI Even Shutdown .
7.3.14 Miscellaneous
Feature Options Description
High Precision Timer Enabled
Disabled Enable/Disable the High Precision Event Timer .
Security
BIOS Security Configuration Submenu
Trusted Computing Submenu
Intel TXT(LT) Configuration Enabled
Disabled Enables or Disables the High Precision Event Timer .
7.3.14.1 Miscellaneous > BIOS Security Configuration
Feature Options Description
SMI Lock Enabled
Disabled Enable or Disable the SMI Lock
BIOS Lock Enabled
Disabled Enable or Disable the BIOS lock enable (BLE) bit
