7.3.4.2 SATA > SATA Port Configuration (IDE)
Feature Options Description
SATA Port Configuration Info only
Serial ATA Port x Info only SATA Port x information
Software Preserve Info only Designates this port as software preserve
SATA-to-PATA Info only PATA devices information
7.3.5 USB
Feature Options Description
USB Module Version Info only
USB Devices Info only X Drive, X Keyboards, X Mouse, X Hubs
Legacy USB Support Enabled
Disabled
Auto Enables legacy USB support .
Auto option disables legacy support if no USB devices are
connected
.
Disable option will keep USB devices available only for EFI
applications and setup
.
EHCI Hand-off Enabled
Disabled This is a workaround for OSes without EHCI hand-off support . The
EHCI ownership change should be claimed by the EHCI OS driver .
USB Mass Storage Driver Support Enabled
Disabled Enable/Disable USB Mass Storage Driver Support .
PCH USB Configuration Submenu
USB hardware delays and time-outs: Info only
USB transfer time-out 1 sec
5 sec
10 sec
20 sec The time-out value for Control, Bulk, and Interrupt transfers
Device reset time-out 10 sec
20 sec
30 sec
40 sec USB mass storage device Start Unit command time-out .
Device power-up delay Auto
Manual Maximum time the device will take before it properly reports itself to
the Host Controller
. 'Auto' uses default value: for a Root port it is 100
ms, for a Hub port the delay is taken from Hub descriptor .
Mass Storage Devices Info only List current USB max stroge device .
7.3.5.1 USB > PCH USB Configuration
Feature Options Description
USB Precondition Disabled
Enabled Precondition work on USB host controller and root ports for
faster enumeration
.
XHCI Mode Disabled
Enabled Mode of operation of xHCI controller .
BTCG Disabled
Enable
Enable/Disable trunk clock gating .
USB Precondition Disabled Precondition work on USB host controller and root ports for
