6.6 PCI Interrupt Routing Map
INT
Line P.E.G
Root Port Audio
Controller ME
Controller #1 GbEt
Controller HDA
Controller PCIE
Port1 PCIE
Port 2 PCIE
Port 3
Int0 INTA:16 INTA:16 INTA:16 INTE:20 INTG:22 INTA:16 INTB:17 INTD:19
Int1 INTD:19 INTB:17 INTC:18 INTA:16
Int2 INTC:18 INTC:18 INTD:19 INTB:17
Int3 INTB:17 INTD:19 INTA:16 INTC:18
INT
Line PCIE
Port 4 PCIE
Port 5 PCIE
Port 6 PCIE
Port 7 PCIE
Port 8 EHIC #1 EHIC #2 LPC
Controller
Int0 INTA:16 INTA:16 INTB:17 INTD:19 INTA:16 INTH:23 INTA:16 INTF:21
Int1 INTB:17 INTB:17 INTC:18 INTA:16 INTB:17 INTD:19
Int2 INTC:18 INTC:18 INTD:19 INTB:17 INTC:18 INTC:18
Int3 INTD:19 INTD:19 INTA:16 INTC:18 INTD:19 INTA:16
INT
Line SATA
Controller #1 SMBus
Controller SATA
Controller #2 Thermal
Subsystem
Int0 INTH:23
Int1 INTD:19 INTD:19
Int2 INTC:18
Int3
6.7 SMBus Slave Addresses
Device Address
DIMM A A0h
DIMM B A4h
BMC 50h
Extend GPIO 40h
