3.3.5 Serial ATA
*Note: SATA1 port not supported by HM86 chipset.
Signal Pin # Description I/O PU/PD Comment
SATA0_TX+
SATA0_TX- A16
A17 Serial ATA channel 0, Transmit Output differential pair. O SATA AC coupled on Module
SATA0_RX+
SATA0_RX- A19
A20 Serial ATA channel 0, Receive Input differential pair. I SATA AC coupled on Module
SATA1_TX+*
SATA1_TX-* B16
B17 Serial ATA channel 1, Transmit Output differential pair. O SATA AC coupled on Module
SATA1_RX+*
SATA1_RX-* B19
B20 Serial ATA channel 1, Receive Input differential pair. I SATA AC coupled on Module
SATA2_TX+
SATA2_TX- A22
A23 Serial ATA channel 2, Transmit Output differential pair. O SATA AC coupled on Module
SATA2_RX+
SATA2_RX- A25
A26 Serial ATA channel 2, Receive Input differential pair. I SATA AC coupled on Module
SATA3_TX+
SATA3_TX- B22
B23 Serial ATA channel 3, Transmit Output differential pair. O SATA AC coupled on Module
SATA3_RX+
SATA3_RX- B25
B26 Serial ATA channel 3, Receive Input differential pair. I SATA AC coupled on Module
(S)ATA_ACT# A28 ATA (parallel and serial) or SAS activity indicator, active low. O 3.3V
