Page 64 Express-HL2
Feature Options Description
Change Settings Auto
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12 Select an optimal setting for Super IO device .
N5104D Super IO Configuration Info only
Serial Port 1 Configuration
Serial
Port
Device
Settings
Change
Settings
Enabled
Disabled
IO=240h; IRQ=10
Auto
IO=240h; IRQ=10
IO=240h; IRQ=10,11,12
IO=248h; IRQ=10,11,12
IO=250h; IRQ=10,11,12
IO=258h; IRQ=10,11,12
Enable/Disable Serial Port (COM)
.
Fixed configuration of serial port
.
Select an optimal setting for Super IO device
.
Serial Port 2 Configuration
Serial
Port
Device
Settings
Change
Settings
Enabled
Disabled
IO=248h; IRQ=11
Auto
IO=248h; IRQ=11
IO=240h; IRQ=10,11,12
IO=248h; IRQ=10,11,12
IO=250h; IRQ=10,11,12
IO=258h; IRQ=10,11,12
Enable/Disable Serial Port (COM)
.
Fixed configuration of serial port
.
Select an optimal setting for Super IO device
.
7.3.9 ACPI and Power Management
Feature Options Description
ACPI and Power Management Info only
Enable ACPI Auto Configuration Enabled
Disabled Enables or Disables BIOS ACPI Auto Configuration .
Enable Hibernation Enabled
Disabled Enables or Disables System ability to Hibernate (OS/S4 Sleep
State)
. This option may be not effective with some OS .
ACPI Sleep State S3 only Select ACPI sleep state the system will enter when the SUSPEND
button is pressed
.
Emulation AT/ATX Emulation AT
ATX
Select Emulation AT or ATX function . If this option set to [Emulation
AT], BIOS will report no suspend functions to ACPI OS . In windows
XP, it will make OS show shutdown message during system
shutdown .
