Introduction • 1
1
Introduction
The ACL-6128A is an ideal cost effective analog output card with two separate
D/A converters
In addition to 12-bit resolution and 16kHz throughput on each
DAC, supporting both voltage and current outputs for industrial applications.
The ACL-6128A provides high voltage isolation on each analog output channel.
Opto-isolators give 2500 V
RMS
isolation to protect both the PC and peripherals
from damage due to high voltages on the inputs. After powering on or resetting
the PC system, both channels will reset the output voltage to 0V in unipolar or
bioplar output range.
The ACL-6128A is fully compatible with the Advantech PCL-728, ensuring an
easy learning curve for customers familiar with Advantech products as well as
an easy replacement with addition functionality. Extra enhancements include
remarkable reliability and performance, surface mount components design, and
single +5V power consumption.
