Table 2-3: usb-1903 pin assignment – ADLINK USB-1903 User Manual

Page 37

background image

Hardware Information

23

USB-1900 Series

Table 2-3: USB-1903 pin assignment

Pin

Function

Pin

Function

40

ECLK

20

AOTG

39

NC

19

AITG

38

NC

18

GPI7

37

GPO3

17

GPI6

36

GPO2

16

GPI5

35

GPO1

15

GPI4

34

GPO0

14

GPI3

33

DGND

13

GPI2

32

AGND

12

GPI1

31

AO1

11

GPI0

30

AO0

10

DGND

29

AGND

9

AISE

28

CI3-

8

CI7-

27

CI3+

7

CI7+

26

CI2-

6

CI6-

25

CI2+

5

CI6+

24

CI1-

4

CI5-

23

CI1+

3

CI5+

22

CI0-

2

CI4-

21

CI0+

1

CI4+
