6 Introduction
1. -3dB small signal bandwidth: (Typical, 25°C, single-ended)
2. System Noise, SFDR, SINAD, THD, SNR (Typical, 25°C, sin-
gle-ended)
3. Effective number of bits (ENOB): (Typical, 25°C,
single-ended)
4. CMRR (DC to 60Hz, Pseudo-differential)
Input Range Bandwidth (-3dB)
± 10 V 600 kHz
± 2 V 630 kHz
± 1 V 660 kHz
± 200 mV 350 kHz
Input
Range
System Noise SFDR SINAD THD SNR
± 10V 0.3 LSB
RMS
108 dB 89 dB 102 dB 89 dB
± 2V 0.1 LSB
RMS
98 dB 85 dB 98 dB 85 dB
± 1V 0.4 LSB
RMS
94 dB 77 dB 89 dB 77 dB
± 200mV 0.8 LSB
RMS
79 dB 67 dB 78 dB 67 dB
Input Range ENOB
± 10V 14.5 bits
± 2V 13.9 bits
± 1V 12.5 bits
± 200mV 10.8 bits
Input Range CMRR
± 10V 90 dB
± 2V 110 dB
± 1V 105 dB
± 200mV 98 dB
