22
Setting the Video Input
The MP­6000MD has four Video Input options; Composite Video, S­Video, Component Video (Y U V) and
DV (DIGITAL) (IEEE 1394).
The selected option is displayed in three ways
LCD Display On­Screen Display
VIDEO = Composite Video
S­VIDEO = S­VIDEO (Y/C)
Y U V = COMPONENT
DIGITAL = DV25 (IEEE 1394)
CVBS = Composite Video
SVIDEO = S­Video
YUV = Component Video
DIGITAL = DV25 (IEEE 1394)
We will concentrate on the LCD display
Press the MENU button, and then go to the Video Input Options
Repeated presses of the Down Arrow button will switch from Composite Video, to S­Video, to Y U V
(Component Video) and finally to DIGITAL (DV25).
Once you have selected the correct input, the video signal from your source should appear on the TV
monitor.
