9 FEATURES
• Full communications with the Telephone system, Intercom system, and Paging system.
• Place and receive outside phone calls
• Make a page through the overhead PA system
• Receive a call from any intercom station (ring or vibration from ANA9500)
• Place a call to an intercom station on a specified channel
• Compatibility with any 2500-set compatible cordless phone, or our specified
ANA9500 900MHz phone.
• Multiple cordless phones in a system, each with its own WP100A interface.
• Up to 2 cordless phones with MC-60/4A system
• Up to 4 cordless phones with the TD-H or TD-Z paging systems
• Compatible with MC-3, two-line system (Max. 1 cordless phone)
^ PRECAUTIONS
BEFORE YOU INSTALL OR OPERATE THE EQUIPMENT
Wireless Interface Adaptor:
1. Do not connect power supply to unit until all wiring connections are complete.
2. Select an Installation location that is accessible, and not exposed to temperature
extremes, moisture, or excessive dust.
3. The optimal place for installation is near the telephone and paging control
equipment.
Wireless Telephone Base Station:
1. In a standard sized facility where usage will be indoors, the base may be
installed near the telephone control equipment or in a Manager’s office.
2. In larger facilities, or where the wireless phone will be used outdoors, the base
station may need to be installed in a remote overhead location in the center of
the facility. If this is the case, an AC outlet must be nearby and a 2-conductor
phone cable must be run from the telephone equipment. When the base is
inaccessible to the user, the optional remote charging cradle (EXP9585) is
required.
A INSTALLATION
ADDITIONAL EQUIPMENT NEEDED FOR INSTALLATION:
• Standard telco interconnect too kit
• Drill
• Tie wraps, tape, wire, hardware
• Screwdriver set
1.
Surface mount WP1OOA to wall or backboard with supplied screws. Unit should be
located near the telephone system and intercom/paging adaptor and amplifier.
AC outlet must be closeby to plug in 24V AC transformer.
2.
Connect WP1 OOA to MC-A/A pagiing adaptor for intercom and PA functions. Wire
connections are made at 12-pin connector, which plugs into socket on WP100A.
Use 2 conductor shielded wire for paging output to MC-A/A. Use 3 conductor wire
to connect one intercom channel to WP100A (2 for power, 1 for communication).
