ATTACHMENTS (Continued)
EDGE-STITCHER
(See page 36)
CLOTH GUIDE
(See page 1 3)
RIPPER
The
ripper
will
help
you
to
cut
opening for the button after a button
hole is completed.
It is also useful for removing seams.
In addition to the aforementioned fittings, needles, bobbins, screwdrivers, oil container and lint brush,
etc. are furnished with the machine.
TO CHANGE THROAT PLATE
1. Raise needle bar and presser foot.
2. Open slide plate.
3. Place thumb under right front end of throat plate
and raise until clamping pin
A
lifts up.
4. Draw throat plate toward right to disengage.
When replacing the throat plate, fit it in the reverse
order.
NOTE: When changing the throat plate, set feed
throw-out lever to “DOWN” position.
TO REPLACE SLIDE PLATE
1. Raise the presser foot and the needle.
2.
Place slide plate in slide way with the front edge
close to, but not covering, the
retaining spring.
3.
With a small screwdriver, lift each end of the spring
into each of the side grooves on the underside of
the slide plate.
4.
Draw the slide plate gently toward you and fully
engage the spring.
5. Close slide plate.
11
