Rif^lR RARTS
SEARS BR0SHWACKER"- - MODEL 3S8.798280
CARBURETOR ASSY. - PART NO. 503-281505
19
□ = Licluded in Gasket Set.
No.
Part
Na
Descripti«!
Kqr
No. Part
No.
llescription
1 502-213901 Choke Shaft 28 504-210050 Spring
2 506-028101 Ch(*e\hlTe 29 503-612301 Idle Speed Mixture Screw
3 501-468701 Screw ■ 30 503-612401 Speed Mixture Screw
4 502-103101 Ttmfttle Spring Bushing 31 5(6-316745 Spring
5 505-316782 East Idle l^er 32 501-463701 ■ Screw
6 502-119701 Choke Shaft Spring 33 502-213301 Throttle Wive
7 603-117001 ftilet Needle Valve 34 502-213401 Throttle Shaft
8 505-520125 Pin 35 502-213801 Pump Cow
9 502-213701 Ehd Inlet Fitting 36 501-68^1 Sprihg
10 601-666101 Fad Inlet Screen 37 503-104701 Idle Adjustment Screw
11 503-625201 Screw (Ind. Wash«:) 38 530-035m Gasket Set Ond. 12.13,20, & 21)
12 □ 502-213601 Pump Diaphragm 39 503-581501 Nozzle
13 o 504-130906 Fud Pump Gadtet
14 501-466901 Screw
15 503-108701 Screw
16
17 501- 468701
502- 213201 Screw
Throttle Lever
'iOT SHOWN _ ■
18 502-103001 Throttle Shaft Spacer
502-114602 Spark Plug Wrench
19 505-316^ Mdering Diaphragm Cover
— 502-026101 Locking Pin
20 d 504-130808 h^tering Diaphragm
— HexK^
210 505-520110 Metering Diaphragm Gasket
— 501-60C№ Screwdriver
22 505-316717 Screw
504-980020 Oil
23 505-520127 hfetering Lever 503-575401 Warning Decal
24 530-035139 Spring 503-575501 DangeryWaming Decal
25 503-574201 Welch Plug
503-804601 Instruction Deca!
26 502-213501 Inlet Valve Seat -
27 504-210049 Spring .
