REPAifi PARTS
SEAES BEUSHWACKER™ - MODEL 368.798280
LOWER END
Key
No.
Part
No.
Description:,;- .
Key
No.
Part
No.
Description
1 502-203106 Anti-Vibe Holder 21 502-203304 Outer Housing
2 503-210722 Screw 24 502-189402 Clutch Housing
3 502-203202 Anti-Vibe Isolator 25 503-161302 Clutch Assembly (Complete)
4 502-197101 Nut 26 503-200230 Screw
5 502-217003 Mounting Bracket Gnd. 16) 27 502-215701 Clutch Hub
6 502-219301 Thumb Screw 28 503-521203 Washer
7 725-238171 Screw 29 502-211101 Drive Shaft & Housing Assy
8 503-098302 En^e Switch (IncL 37)
9 502-199301 Spring 30 502-212901 Gearbox Plug
10 502-199104 TTirottle Handle (right side) 31 502-031003 Support Flange
12 503-210738 Screw 32 502-045501 Nut
13 502-196002 Handlebar (Incl. 14 & 20) 33 502-194601 Driving Disk
14 502-211201 Clip 34 503-200225 Screw .
15 502-204901 Clip 35 502-1^001 Gearbox As^. (Incl. 30)
16 502-217003 Motmtlng Bracket G^cL 5 ) 36 502-193601 Gearbox Seal
17 502-199002 Throttle Handle (left side) 37 502-211101 Drive Shaft & Housing Assembly
18 502-199203 Throttle Tri^er (hicL29)
19 502-199403 Throttle Trigger Lock 38 731-231401 Nut
20 502-199702 Handle Grip 39 503-200230 Screw
40 503-210725 Screw
- 2 7 -
