repair parts
PARTS LIST FOR CRAFTSMAN BELT AND DISC SANDER
MODEL 113.226430
Key
No.
Part
No. Description
1 820247 Knob
2 820175 Washer, Rubber
3 821156 Washer, Notched
4 819496 Bed
5 820235 Screw, Flat Cross
M5 X 0.8-35
6 820249 Screw, Hex M6 x 1.0-12
7 STD852006 * Lockwasher, Ext. M6
8 820238 Washer. 6.5 x 17.8 x 1.6
9 819481 Support, Work
10 9-28394 t Belt, Sanding 4" x 36"
11 820383-4 Lockwasher. Helical M5
12 820240-1 Screw, Pan Hd M5 x 0.8-8
13 819476 Drum. Drive
14 820245 Screw, Socket Set
M6x 1.0-10
15 820243 Cap, Bearing
16 814101 Bearing, Ball
17 820618 Spacer, Bearing
18 819491 Housing Switch
19 STD852005 * Lockwasher. Ext. M5
20 820240 Screw, Pan Hd, M5 x 0.8-16
21 9-2225 t Key, Switch
22 816113 ik Switch, Locking
23 819461 Lead
24 820248-1 Screw, Pan Cross
Type"AB" M4.2X 1.4-30
25 819479 Cover, Switch Box
26 814589 * Relay
27 9-28308 t Pad, 6" Sandpaper
28 820244 Screw; Pan Cross
M6x 1.0-12
29 819485 Casting, Disk
30 820248 Screw, Pan Hd Type "AB"
M4.2x 1.4-12
31 819484 Guard, Disk
32 819497 Shroud, Disk
33 819495 Collector, Dust
34 819487 Table
* Standard Hardware item - May be purchased iocaliy.
t Stock Item - May be secured through the Hardware
Department of most Sears Retail Stores and Catalog
Order Houses.
• Relay must accompany motor when motor is returned
for service. Any attempt to repair this motor may
Key
No.
Part
No. Description
35 819490 Support, Tabie
36 819459 Label, Scale
37 819463 Cord W/Plug
38 820012 A® Motor (1/3 HP)
39 803709 Connector, Wire
40 STD840610 * Nut, Hex M6 X 1,0
41 819498 Base
42 814002-1 Belt, Drive
43 820242-1 ^ Ring, Retaining M15
44 820510-4 Washer, Spring
45 819486-1 Pulley, Drive
46 820244-1 Screw, Pan Hd. M6x 1.0-25
47 820383-5 Lockwasher, Helical M6
48 STD851006 * Washer, M6 x 12 x 1.6
49 820242 A Ring, Retaining Ml2
50 820510 Washer, Spring
51 819486 Pulley, Drive
52 820235-1 Screw, Flat Hd. M5 x 0.8-25
53 819473 Support, Bearing
54 820235-2 Screw, Flat Cross
M5x 0.8-10
55 819474 Cover, Belt
56 819482 Support, Bed
57 820258-4 Nut, Square M8 x 1.25
58 820239 Screw, Hex Soc. Cap
M8x 1.25-25
59 820779 Bumper, Rubber
60 819478 Shaft. Drive
61 STD840508 Nut, Hex M5 X 0.8
62 819465 Spacer, Guide
63 63658 Spring, Index
64 819475 Drum, Idler
65 819462 Shaft, Idier
66 819488 Guide, Drum
67 819470 Lever, Tension
68 819468 Spring, Tension
69 819471 Spacer, Lever
70 STD851005 * Washer, M5x 15x 1.2
— SP5406 Owner’s Manual (Not illus.)
813317-9 Hex “L” Wrench 6mm
(Not lltus.)
create a hazard unless repair is done by a qualified
service technician. Repair service is available at your
nearest Sears store.
A WARNING: These Items Are Important To The
Safety Of This Tool. Do Not Substitute Common
Parts.
23
