The wofktabte can be tilted from 0" to 45® for bevel
sanding. Loosen the table lock knob and titt the work
table to desired angle as shown. Retighten table lod<
knob^
WARNING! To avoid trapping the work or fingers
between the table and sanding surface, the table
amaximum of 1/16 Inch distance between sanding
surface and table.
\
0 //
i
11
1/IM
mi
m
—ineiHCH MAXIMUM
-SAMOIHG SUflFACE
POSITIONING BELT BED
WORK SUPPORT
BELT BED
A bed locking hex socket head screw locks the belt bed
in a vertical or horizontaf position.
To adjust vertical ppsition:
1. Re move the wo ik support.
HEX SOCKET
SCREW
HEX ”L" WRENCH
2. Loosen the hex socket head locking screw using a
6mm hex wrench.
3. Position belt bed vertically as shown and tighten the
hex socket head screw.
