Always order by Part Number—Not by Key Number
FIGURE 1
PARTS LIST FOR CRAFTSMAN 8" DRILL PRESS
MODEL NO. 113.213080
m
“O
m
•o
m
m
Key
No. Part
No.
Description
1 817771 Head w/Roll Pin & Trim
2 817449 Nut-Lock M8 X1.25-8
3 STD551031 * Washer-5/16x11/16x1/16
4 STD835025 * Screw-Hex M8x 1.25-25
5 817427 , Pulley-Motor
6 817391-3 Screw-Hex Soc. Set
M6x 1.0-6
7 817420 »Motor
8 817445 Stop-Motor
9 817444 Spring-Motor Stop
10 817421 Knob-Motor Adjusting
11 817391-2 Screw-Hex Soc. Set
M8x 1.25-8
12 817439 Knob
13 817438 Rod
14 817409 Shaft-Pinion
15 STD840812 *Nut-Hex M8X1.25
16 817442 Screw-Fit. Sit. Set M8x 1.25
17 STD852005 *Lockwasher-Ext. 5mm
18 816755-4 Screw-Pan Hd. M5 x 0.8-8
19 817770 Box-Switch w/Depth Scale
20 816755-3 Screw-Pan Cr. M5x0.8-12
Key
No.
Part
No.
Description
21 816113 Switch-Locking
22 817357 Screw-Self tap. pan
hd. M4X16-8
23 817422 Cover-Switch Plate
24 815863 Key-Switch
25 STD375008 *Connector-Wire
26 817406 Seat-Spring
27 817443 Retainer-Spring
28 817415 Spring-Tension
29 817416 Cap-Spring
30 STD541137 * Nut-Hex 3/8-24
31 STD841015 *NutHexM10x1,5
32 817419 Pointer
33 817329-1 Cord-Power
34 813317-7 Wrench Hex “L" 4mm
— 507871 Bag of Loose Parts
(Not Illustrated)
— 507870 Box of Loose Parts
(Not Illustrated)
SP5184 Owners Manual
(Not Illustrated)
* standard Hardware Item - May Be Purchased Locally.
9 Any attempt to repair this motor may create a HAZARD unless repair is done by a qualfied service technician.
Repair service is available at your nearest Sears Store.
Repair Parts
