21
VZ7656 Standard Object Types Supported
Object Type Supported
Dynamically
Creatable
Dynamically
Removable
Optional
Properties
Supported Writable Properties
Analog Input    Reliability Out_of_Service
Analog Value    Reliability
Present_Value
a
Out_of_Service
Binary Input   
Reliability
Active_Text
Inactive_Text
Out_of_Service
Binary Value   
Reliability
Active_Text
Inactive_Text
Present_Value
b
Out_of_Service
Device   
Max_Master
Max_Info_frames
Object_Identifier
Object_name
Max_Master
Multi-state Value   
Reliability
States_Text
Present_Value
c
Out_of_Service
Schedule    Weekly_schedule Read Only
a: Present_Value property is writable for every AV objects except :
 Cfg RTC MAC (AV 1)
 GUI Current Zone PI Heat Demand (AV 11)
 GUI Current Zone PI Cool Demand (AV 12)
 GUI Transferred PI Heat Demand (AV 13)
 GUI Transferred PI Cool Demand (AV 14)
 GUI Highest PI Heat Zone (AV 15)
 GUI Highest PI Cool Zone (AV 16)
 GUI Highest PI Heat Demand (AV 17)
 GUI Highest PI Cool Demand (AV 18)
 Cfg Device Instance (AV 21)
b: Present_Value and Out_of_Service properties are writable for every BV objects except :
 Sta Comm Lost Status (BV 3)
 Sta Smart Recovery (BV 7)
c: Present_Value and Out_of_Service properties are writable for every MV objects except :
 Cfg RTC Baud (MV 1)
 GUI Zone Sequence (MV 4)
