Viconics VZ7260(X) VZ7656(X) BACnet Installation Manual - Manual (Page 14)

14
VZ7260 List of Property Enumeration Sets for BI and BV objects
Object Name
Object Type and
instance
Inactive_Text Active_Text
Default
value
GUI BI 1 Status BI 1 Not Activated Activated Not Activated
GUI BI 2 Status BI 2 Not Activated Activated Not Activated
Cfg Temperature Scale BV 1 °C °F °F
Cfg Menu Scroll BV 2 No Scroll Scroll Active Scroll Active
Cfg Motion Detector
Function
BV 3 Not Activated Activated Not Activated
Cfg AO2 RA/DA BV 4 Direct Acting
Reverse
Acting
Direct Acting
Cfg BO5 Time Base BV 5 15 Minutes 10 Seconds 15 Minutes
Cfg BO5 Configuration BV 6 N.O. N.C. N.O.
GUI BO5 Status BV 7 Off On Off
Sta AO2 Lock Status BV 8 Not Activated Activated Not Activated
Sta BO5 Lock Status BV 9 Not Activated Activated Not Activated
GUI Room Temp Override BV 10 Normal Override Normal
Sta RTC Prog Recovery BV 11 Off On Off
Cfg Setpoint Type BV 12 Permanent Temporary Permanent
Cfg Disable Min Pos BV 13 Enabled Disabled Disabled
Sta BO3-BO4 Lock Status BV 14 Inactive Active Inactive
