Viconics VZ7260(X) VZ7656(X) BACnet Installation Manual - Manual (Page 20)

20
VZ7656 Device Object Table
Object Name
Type and
Instance
Object Property Controller Parameter
VZ7656 Device Object_Identifier
Property 75 (R,W)
Unique ID number of a device on a network
Object_Name
Property 77 (R,W)
Unique name of a Device on a network
Model Name
Property 70 (R)
Controller Model number
Firmware Revision
Property 44 (R)
Current BACnet firmware revision used by the
controller
Protocol Version
Property 98 (R)
Current BACnet firmware protocol version
Default is Version 1
Protocol Revision
Property 139 (R)
Current BACnet firmware protocol revision
Default is Version 2
Max ADPU Length
Property 62 (R)
Maximum ADPU Length accepted
Default is 244
ADPU Timeout
Property 10 (R)
ADPU timeout value
Default is60 000 ms
Max_Master (R,W) Maximum master devices allowed to be part of the
network. 0 to 127, default is 127
