16
Object Name
Object
Type and
instance
BACnet Index Text Default value
Network Handle MV 7
1 Default Zone Handle
Default Zone
Handle 2 Default Minus
Occupancy
3 Full Release
This property is used to release the functions of the VZ7260 Zone controller from its attached master RTC VZ7656. It is used
when remote scheduling of the zones are required externally to the master VZ7656 RTU controller or when integration is
required without a VZ7656 RTU controller
.
Network Handle Occupancy PI Heat
Weighted PI Cool
Weighted Prog Rec
Enabled RTC
Sequence
1 = Default Zone
Handling
From the
VZ76
To the VZ76 To the VZ76
From the
VZ76
From the
VZ76
2 = Zone Handling
minus occupancy
To the VZ76 To the VZ76
From the
VZ76
From the
VZ76
3 = Full Release The VZ7260 controller will operate without any dependencies from the VZ7656
RTU controller. It can be fully integrated with any supervision device for control
and operation
Object Name
Object
Type and
instance
BACnet Index Text Default value
Cfg Zone Keypad
Lockout
MV 8
1 Level 0
Level 0
2 Level 1
3 Level 2
4 Level 3
GUI Occupancy
Command
MV 9
1 Local Occupancy
Local Occupancy 2 Occupied
3 Unoccupied
Cfg RTC Zone
Sequencing
MV 10
1 Cool
Cool
2 Heat
GUI Effective
Occupancy
MV 11
1 Occupied
Depends on local
occupancy 2 Unoccupied
3 Temporary Occupied
4 Stand-by
Cfg BO1-BO2
Floating Time
MV 12
1 0.5 minutes
1. 5 minutes
2 1 minute
3 1.5 minutes
4 2 minutes
5 2.5 minutes
6 3 minutes
7 3.5 minutes
8 4 minutes
9 4.5 minutes
10 5 minutes
11 5.5 minutes
12 6 minutes
13 6.5 minutes
14 7 minutes
15 7.5 minutes
16 8 minutes
17 8.5 minutes
18 9 minutes
