USL DAX-16 - Manual (Page 7)

DAX-­‐16
Installation
&
Operation
Manual
Rev
1.4
7
Please
contact
your
dealer
or
USL,
Inc.,
with
questions
regarding
the
proper
disposal
of
this
or
any
other
USL
product.
USL,
Inc.
contact
information:
USL,
Inc.,
181
Bonetti
Drive,
San
Luis
Obispo,
CA
93401-­‐
7397,
USA.
Phone:
+1
805
549
0161
Fax:
+1
805
549
0163
www.uslinc.com
Introduction
The
DAX-­‐16
is
a
versatile
digital
to
analog
converter
designed
for
cinema
applications.
It
converts
16
channels
of
AES/EBU
or
Harman
BLU
link
to
analog.
The
analog
outputs
are
on
DE-­‐15
(also
called
HD-­‐15)
connectors
to
directly
drive
amplifiers.
The
DAX-­‐16
accepts
48k
and
96k
sample
rates.
The
DAX-­‐16
includes
channel
routing,
allowing
any
channel
of
the
digital
input
signal
to
be
routed
to
any
output.
The
DAX-­‐16
also
serves
as
a
remote
booth
monitor.
A
local
or
remote
web
browser
can
view
a
bar
graph
showing
all
the
audio
channels.
The
DAX-­‐16
also
streams
a
user
selected
mix
of
the
audio
for
remote
monitoring
of
the
system.
Both
the
bar
graph
and
the
streaming
audio
can
monitor
the
analog
audio
leaving
the
DAX-­‐16,
or
audio
returned
from
the
amplifier
outputs
(“Vmon”).
The
monitor
bus
can
be
cascaded
between
multiple
units
allowing
a
single
audio
stream
to
contain
a
mix
of
audio
from
the
multiple
units.
Outputs
can
be
named
by
the
user
to
indicate
a
speaker
position
and
band
(for
applications
where
the
crossover
is
in
the
sound
processor).
Buttons
and
level
indicators
take
on
the
user
defined
names,
which
can
be
in
any
language.
The
front
panel
includes
signal
present
LEDs
to
quickly
verify
operation.
The
system
includes
“bypass”
circuitry
to
allow
continued
operation
in
the
unlikely
event
of
the
failure
of
the
sound
processor
or
the
DAX-­‐16.
The
bypass
circuitry
includes
a
passive
crossover
for
biamp
and
triamp
operation.
The
DAX-­‐16
saves
a
backup
copy
of
its
settings
on
an
SD
card
so
they
can
be
easily
loaded
into
another
unit.
Features
• Ideal
for
control
room
installations
or
where
amplifiers
are
behind
screen
or
under
seats
• High
quality
audio
• 16
channels
of
AES/EBU
input
on
two
RJ-­‐45
connectors
• 256
(48kHz)
or
128
(96kHz)
channels
of
BLU
link
input
on
two
RJ-­‐45
connectors
• Compatible
with
Dolby®
CP850
Atmos™
Connect
• Outputs
on
8
DE-­‐15
(HD-­‐15)
connectors
to
directly
drive
amplifiers
• Web
browser
display
of
output
levels
and
amplifier
return
levels
• Selected
channels
of
output
audio
or
amplifier
return
audio
streamed
to
web
browser
• Channel
routing
–
Each
output
can
be
driven
by
any
input
• Output
trims
for
each
output
• Servo
balanced
outputs
drive
balanced
or
unbalanced
loads.
• Front
panel
signal
presence
indicators
• Web
browser
display
of
AES/EBU
or
BLU
link
status
