Page 44
5-4
Commands
• This command should not be used within the data sequence of
another command that consists of 2 or more bytes. For example,
If you attempt to transmit ESC 3 n to the printer, but DTR (DSR
for the host computer) goes to MARK before n is transmitted
and then DLE EOT 3 interrupts before n is received, the code
<10>H for DLE EOT 3 is processed as the code for ESC 3
<10>H.
• When Auto Status Back (ASB) is enabled using the GS a
command, the status transmitted by the DLE EOT command and
the ASB status must be differentiated.
• If the n is out of the specified range, the printer ignores this
command.
n = 1: Printer status
n = 2: Off-line status
Bit Off/On
Hex Decimal
Function
0
Off
00
0
Not used. Fixed to Off.
1
On
02
2
Not used. Fixed to On.
2
Off
00
0
Drawer kick-out signal is LOW (connector pin 3)
On
04
4
Drawer kick-out signal is HIGH (connector pin 3)
3
Off
00
0
On-line.
On
08
8
Off-line.
4
On
10
16
Not used. Fixed to On.
5
Off
00
0
Undefined.
On
20
32
Undefined.
6
Off
00
0
Undefined.
On
40
64
Undefined.
7
Off
00
0
Not used. Fixed to Off.
Bit
Off/On
Hex
Decimal
Function
0
Off
00
0
Not used. Fixed to Off.
1
On
02
2
Not used. Fixed to On.
2
Off
00
0
Undefined.
On
04 4
Undefined.
