Taking Out What You Need
Taking Out What You Need
Remove the items shown in
from the shipping container:
Figure C-1
The Catalyst 3750 Metro Switch, Adapter Cable, and AC Power Cord
Note
If you are using a DC power supply, see the
“Connecting to DC Power” section on page 3-4
for more
information about setting up your switch with a DC power supply.
Note
You need to provide the Category 5 or higher straight-through cables to connect the switch ports to other
Ethernet devices.
1
Switch
3
AC power cord
2
RJ-45-to-DB-9 adapter cable
