B-3
Catalyst 3750 Metro Switch Hardware Installation Guide
OL-9160-02
Appendix B Connector and Cable Specifications
Connector Specifications
Figure B-2 MT-RJ Connector
Connecting to 1000BASE-T Devices
When you connect the ports to 1000BASE-T devices, such as servers, workstations, and routers, you
must use a four twisted-pair, Category 5 or higher, straight-through cable wired for 10BASE-T,
100BASE-TX, and 1000BASE-T.
Figure B-10 on page B-8 shows the straight-through cable schematics.
When you connect the ports to other devices, such as switches or repeaters, you must use a four
twisted-pair, Category 5, crossover cable.
Figure B-11 on page B-9 shows the crossover cable
schematics.
• Be sure to use a four twisted-pair, Category 5 or higher cable when you connect to a
1000BASE-T-compatible device.
• Use a straight-through cable to connect two ports only when one port is designated with an X. Use
a crossover cable to connect two ports when both ports are designated with an X or when both ports
do not have an X.
• You can use Category 3, 4, or 5 cabling when connecting to 10BASE-T-compatible devices. You
must use Category 5 or higher cabling when you connect to 100BASE-TX-compatible devices.
Table B-1 MT-RJ Patch Cables for 100BASE-FX Connections
Type Cisco Part Number
1-meter, MT-RJ-to-SC multimode cable CAB-MTRJ-SC-MM-1M
3-meter, MT-RJ-to-SC multimode cable CAB-MTRJ-SC-MM-3M
5-meter, MT-RJ-to-SC multimode cable CAB-MTRJ-SC-MM-5M
1-meter, MT-RJ-to-ST multimode cable CAB-MTRJ-ST-MM-1M
3-meter, MT-RJ-to-ST multimode cable CAB-MTRJ-ST-MM-3M
5-meter, MT-RJ-to-ST multimode cable CAB-MTRJ-ST-MM-5M
