B-1
Catalyst 3750 Metro Switch Hardware Installation Guide
OL-9160-02
A P P E N D I X
B
Connector and Cable Specifications
This appendix describes the Catalyst 3750 Metro switch ports and the cables and adapters that you use
to connect the switch to other devices, and includes these sections:
•
Connector Specifications, page B-1
•
Cable and Adapter Specifications, page B-5
Connector Specifications
These sections describe the connectors used with the switch, and includes these sections:
•
•
•
10/100 Ports
The 10/100 Ethernet ports use standard RJ-45 connectors and Ethernet pinouts with internal crossovers,
as shown by an X in the port name. These ports have the transmit (TD) and receive (RD) signals
internally crossed so that a twisted-pair straight-through cable and adapter can be attached to the port.
shows the pinouts.
