INSTALLATION MANUAL
SpeAker rIggINg brAckeTS HY-VM7b
HY-VM7W
Thank you for purchasing TOA’s Speaker Rigging Bracket.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TAbLe OF cONTeNTS
1. SAFeTY precAUTIONS ..................................................................................................................... 1
2. geNerAL DeScrIpTION ................................................................................................................... 2
3. MOUNTINg THe SpeAker ON A WALL (using the optional HY-WM7b or HY-WM7W bracket) ........ 2
4. MOUNTINg THe SpeAker TO A ceILINg (using the optional HY-c0801 or HY-c0801W bracket) .. 6
5. SUSpeNDINg THe SpeAker FrOM A ceILINg (only the T-bracket is used) ............................. 8
6. DIrecT SpeAker ceILINg MOUNTINg (only the T-bracket is used) ........................................ 10
7. SpecIFIcATIONS ............................................................................................................................... 12
1. SAFeTY precAUTIONS
• Before installation or use, be sure to carefully read
all the instructions in this section for correct and
safe operation.
• Be sure to follow all the precautionary instructions
in this section, which contain important warnings
and/or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
• Refer all installation work to the dealer from whom
the speaker was purchased. Installation for flying
requires extensive technical knowledge and
experience. The speaker may fall off if incorrectly
installed, resulting in possible personal injury.
• Flying Precautions
Be sure to follow the instructions below. Otherwise,
the suspension wires or belts may be off or snap
and the speaker may fall off, causing personal
injury.
· Check to confirm that the suspension wires and
belts are strong enough to withstand the speaker
load.
· The connectors of the suspension wires and belts
must be securely linked with those of the speaker.
· All parts and components (such as enclosures,
metal pieces, and screws) must be free from any
deformation, crack, and corrosion.
· Be sure to use screws supplied with the optional
flying hardware when installing the speaker using
such hardware.
• Install the speaker only in a location that can
structurally support the weight of the speaker and
the mounting bracket. Doing otherwise may result
in the speaker falling down and causing personal
injury and/or property damage.
• Since the bracket is designed for indoor use, do not
install it outdoors. If installed outdoors, the aging
of parts causes the speaker to fall off, resulting in
personal injury. Also, when it gets wet with rain,
there is a danger of electric shock.
• Owing to the speaker’s size and weight, be sure
that at least two persons are available to install the
speaker. Failure to do so could result in personal
injury.
• Do not use other methods than specified to mount
the bracket. Extreme force is applied to the bracket
and the speaker could fall off, possibly resulting in
personal injuries.
• Attach the safety wire to the speaker. If not attached,
it could fall off, resulting in personal injury.
• Use safety wires when installing speakers. If not
used, personal injury could result if a speaker
should accidentally fall.
• Use nuts and bolts that are appropriate for the
ceiling’s or wall’s structure and composition. Failure
to do so may cause the speaker to fall, resulting in
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
WArNINg
