10.0 .22 LR Caliber Conversion (optional)
1. Remove barrel (see section 8.3)
2. Remove magazine ejector. Unhook the magazine ejector
spring 301 downwards from its upper retainer and allow it
to relax.
3. Now unhook the lower claw from the magazine ejector 302
and remove it.
4. Lift the bottom end of the magazine ejector, swing it to the
left and remove it from the upper aperture.
Figure 19
301
Figure 20
302
