www.sigsauer.com 45
7.2 Installing the cheekrest
1. The cheekpiece has two similar openings for the releases.
The opening with the v-notch aimed downward identifies the
right side of the cheekpiece.
2. Place the cheekpiece on top of its recess in the stock,
and force it downward, one side at a time, into its highest
adjustment position. Ensure that the openings for the releases
are aligned with the slot in the stock.
3. Insert the releases into the opposite openings in the
cheekpiece so they engage and lock.
7.3 Stock adjustment options
7.3.1 Adjusting cheekpiece height
1. With a pinching grasp, depress both releases at the same time.
2. Raise or lower the cheekrest to the desired height.
3. Release the grasp on the releases while settling the
cheekrest into the nearest adjustment position.
Figure 13
Figure 14
