Figure 3, Cocking the bolt Figure 4, Cocking indicator of the bolt
(left: decocked, right cocked)
5.6 Bolt
5.6.1 Cocking the bolt
Before the bolt 100 can be inserted into the Rifle, the firing pin must first be cocked.
A cocking indicator displays whether the bolt is cocked or not (red = cocked).
1. Insert the tapered end of the supplied key into the side opening of the lock 113. (Figure 3)
2. Turn the lock towards the cocking wheel until it engages. (Figure 4)
