5.8.1 Setting the take-up
Reduce take-up:
– Turn set screw 709b clockwise.
Increase take-up:
– Turn set screw 709b counter-clockwise.
CAUTION! Rifle may be damaged
• The screw for reducing the take-up must only be turned clockwise to a degree that the safety lock will still work properly.
• If the free movement of the safety lock is impeded, the screw must be immediately turned back anti-clockwise until the
normal safety lock function is restored.
Note:
• When setting the take-up, the trigger must be in a position that allows access to set screw 709b.
• The take-up travel cannot be adjusted to “zero”, there will always be a travel by design.
Figure 8
709a 711
709b
710
