1 . Select panel location away from direct contact with water
and oil .
2 . Confirm clearance for wire connections behind wall, hull liner
or bulkhead .
3. Using control panel template (fig. 8 , page 5), cut out
panel access hole (E, F) and drill fastener holes (G).
4 . With electrical power off, route 18-gauge stranded copper
wire from power source, through circuit breaker or fuse (not
provided), to panel location. Route additional wire according
to diagram (fig. 4 , page 3 – see wiring diagram key
below), depending on your application, to panel location.
Make sure wires extend out through access hole .
5 . Make proper wiring connections to wires extending from
bottom of circuit panel (fig. 3 A 2, page 3).
6. Remove panel cover (fig. 3 A 1, page 3) from circuit panel/
mounting frame (A 2), if necessary, by carefully pulling them
apart .
7. Install mounting frame to wall with four fasteners (fig. 3 A 3).
8 . Push panel cover onto mounting frame until it locks into
place .
1. At step 4 (above), route and connect 14-gauge stranded copper wires according to wiring diagram
(fig. 4 , page 3) and wiring diagram key (see below).
2 . Insert “Full Tank” shut-down relay into receptacle on back of circuit panel .
6.1
Tank Monitor Panel
(fig. 3 A, page 2)
6.2
“Full Tank” Shut-down Relay (optional accessory)
(fig. 1 4, page 2)
DTM04 Panel Template
Dimensions
(fig. x , page 5)
3
1
Dometic Tank Monitor System
Specifications
Caution!
Do not install DTM04 panel in an atmosphere with potentially flammable or
explosive vapors.
Ref.
Dimension
A
83 mm / 3.25 in.
B
83 mm / 3.25 in.
C
67 mm / 2.63 in,
D
67 mm / 2.63 in.
E
55 mm / 2.16 in.
F
68 mm / 2.69 in.
G
2 mm / 0.10 in. dia.
H
Cut-out area .
Allow 51 mm / 2 in.
clearance behind wall .
6
6
4
4
43
3
3
5.3 Dimensions
(fig. 2 , page 2)
5.4 Approvals
ISO 8846; EMC Directive 2004/108/EC
Ref.
Dimension
A
83 mm / 3.25 in.
B
83 mm / 3.25 in.
C
51 mm / 2 in. clearance behind wall
D
10 mm / 0.38 in.
2
Ref.
Dimension
E
111 mm / 4.375 in.
F
25 mm / 1.0 in.
G
527 mm / 20.75 in.
H
69 mm / 2.75 in.
6 Installation
