SeaLand Bowl Kit Installation User Manual
SeaLand Hardware

342341 4/02 © 2002 Dometic Corporation
Dometic Corporation
SeaLand Product Group
13128 State Rt 226
PO Box 38
Big Prairie, OH 44611
1-800-321-9886
BOWL KIT INSTALLATION INSTRUCTIONS
TO REMOVE OLD BOWL
1. Turn off water supply.
2. Press flush pedal and drain water from toilet bowl.
3. Remove pedal and pedestal covers (if applicable).
4. Loosen stainless steel band and remove plastic half clamps that hold china
bowl and plastic base together. CAUTION: Do not let china bowl fall off base.
5. Tilt china bowl forward, grasp vacuum breaker attached to back of toilet, and
pull it out of toilet. (On toilets manufactured before 10/96, loosen plastic
locknut on vacuum breaker and remove from china bowl.) Set toilet bowl
aside.
6. Inspect bowl seals and flush ball for nicks, scratches or mineral build-up.
Clean or replace as necessary.
TO INSTALL NEW BOWL
7. Put new china bowl on base. Align notch with pin on base, and center the
bowl outlet over the flush ball. Reattach vacuum breaker to back of toilet,
pushing it all the way into the rubber gasket. (On toilets manufactured before
10/96, tighten plastic locknut on vacuum breaker.)
8. Reinstall plastic half clamps under loosened steel band, making sure tabs
interlock on front of toilet. There will be a small gap at the rear of the toilet.
9. Tighten stainless steel band clamp to 65 in.-lbs. of torque.
10. Turn on water supply.
11. Reinstall pedestal and pedal covers (if applicable).
342341 4/02 © 2002 Dometic Corporation
Dometic Corporation
SeaLand Product Group
13128 State Rt 226
PO Box 38
Big Prairie, OH 44611
1-800-321-9886
BOWL KIT INSTALLATION INSTRUCTIONS
TO REMOVE OLD BOWL
1. Turn off water supply.
2. Press flush pedal and drain water from toilet bowl.
3. Remove pedal and pedestal covers (if applicable).
4. Loosen stainless steel band and remove plastic half clamps that hold china
bowl and plastic base together. CAUTION: Do not let china bowl fall off base.
5. Tilt china bowl forward, grasp vacuum breaker attached to back of toilet, and
pull it out of toilet. (On toilets manufactured before 10/96, loosen plastic
locknut on vacuum breaker and remove from china bowl.) Set toilet bowl
aside.
6. Inspect bowl seals and flush ball for nicks, scratches or mineral build-up.
Clean or replace as necessary.
TO INSTALL NEW BOWL
7. Put new china bowl on base. Align notch with pin on base, and center the
bowl outlet over the flush ball. Reattach vacuum breaker to back of toilet,
pushing it all the way into the rubber gasket. (On toilets manufactured before
10/96, tighten plastic locknut on vacuum breaker.)
8. Reinstall plastic half clamps under loosened steel band, making sure tabs
interlock on front of toilet. There will be a small gap at the rear of the toilet.
9. Tighten stainless steel band clamp to 65 in.-lbs. of torque.
10. Turn on water supply.
11. Reinstall pedestal and pedal covers (if applicable).
