8
Dometic Tank Monitor System Intended use
System Voltage Amp
12 V DC
without shut-down relay
with shut-down relay
0 .008
0 .145
24 V DC
without shut-down relay
with shut-down relay
0 .004
0 .090
Specifications subject to change without notice .
4 Components
Items in fig.
1 page 2
Description Item Number (Europe / North America)
1 DTM04 cover panel 860003853114778 / 385311477
2
DTM04 circuit panel/
mounting frame
860003853114836 / 385311483
3 #6 fastener 860003853116120 / 385311612
4
“Full Tank” shut-down relay
(available separately) 9107100013 / 385311579 – 12 V DC
9107100014 / 385311580 – 24 V DC
5 Compression nut kit 860003853102583 / 385310258
6 Float/stem kit 860003852302689 / 385230268
7 Float/lock ring kit 860003853111030 / 385311103
8 Flexible probe kit 860003852309304 / 385230930
9 O-ring 860003853112509 / 385311250
10 Probe cap/O-ring 860003853116179 / 385311617
1
5 Specifications
5.1 Materials
3.3 Features
“Power on” indicator. One Tank Monitor panel light is always lit to assure system operation .
Long-lasting, foul-proof tank probes. Semi-flexible probe stems move with tank contents to reduce
stress . Integral sensor delay prevents false readings .
Probe cap fits Dometic DHT-L series holding tanks. Also fits other tanks equipped with 76 mm (3 in.)
NPT opening in top of tank .
For holding tanks up to 56 cm (22 in.) deep. Flexible probes can be adjusted to fit many tank sizes .
12 or 24 V DC operation.
5.2 Electrical Current Draw
Panel frame and mounting frame: ABS
Panel surface: Polycarbonate resin
Circuit breaker or fuse
required for DTM04 panel:
1 amp
Maximum shut-down relay
rating for 12 or 24 V DC
toilet system:
30 amps
Probe cap: PVC
Floats: Nitrile rubber ebonite
