7
1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8
4 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 10
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Warranty and Product Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 12
1 Notes on using the manual
Note
Supplementary information for operating the device .
fig. 2 A, page 2 : This refers to an element in an illustration . In this example, item A in
figure 2 on page 2 . 2
Caution!
Safety Instruction: Failure to observe this instruction can cause material damage and
impair the function of the device .
EN Table of contents
Dometic Tank Monitor System Notes on using the manual
2 General safety instructions
The manufacturer will not be held liable for claims for damage resulting from the following:
• Faulty assembly or connection
• Damage to the unit from mechanical influences, misuse or abuse
• Float switches fouled with tissue paper
• Alterations to the unit without express written permission from the manufacturer
• Use for purposes other than those described in this manual
3 Intended use
3.1 OPTION 1: DTM04 tank monitor system
DTM04 Tank Monitor System provides electronic monitoring of the liquid level inside a holding tank.
Three float switches inside the tank activate a set of four lights on an indicator panel. The lights indicate
Empty, Low, Mid and Full levels. The Full level indicates when the liquid level is within 51 mm (2 in.) of
the top of the holding tank. The other float switches are connected to adjustable probe stems which
can be positioned according to the tank height and the desired indicator panel readings .
3.2 OPTION 2: DTM04 tank monitor system with “full tank” shut-down relay
When the optional “Full Tank” Shut-down Relay (available separately) is connected to the DTM04 panel,
and the holding tank reaches the Full level, the relay shuts off power to the electric toilet . This prevents
use of the toilet and the possibility of overfilling the holding tank . See Components for “Full Tank” Shut-
down Relay item numbers . The relay handles a maximum electrical current of 30 amps .
