Page 16

background image

Optional wire grid

to increase radiant

efficiency

Standard Reflector

Optional Parabolic Reflector

10.0 Accessories

Heat Deflector, Option DO2

A heat deflector is available on Sizes 30-100 to permit less clearance above the heater.

See Paragraph 4.

Chain and "S" Hooks, Option UE1

Option kit includes 50 ft (15M) of 200 lb (91 kg) chain and 14 "S" hooks.

Chain Mounting Kit, Option UE2

Option kit includes assembled chain and "S" hooks for mounting one unit (See

FIGURE

4, page 8).

Gas Connector and Shutoff Valve, Option UF2

Option kit includes a 24" stainless steel gas connector and shutoff valve.

Standard

Reflector

Optional Screen

The following are field-installed accessories. Follow the instructions shipped with the

option package.

Thermostat, Option CL34

is a 24/120 volt thermostat that can be used to control

1-5 units. This thermostat can also be used to control the exhaust fan circuit.

Thermostat, Option CL82

is a 24-volt, 2-stage digital thermostat that can be

used with Option AG2R for automatic control of 1-5 units.

Parabolic Reflector, Option DM2

The addition of the parabolic reflector

increases the infrared intensity pattern

while decreasing the scope of heating

coverage.

Installation affects clearances and mounting height; see page 7.

Wire Grid, Option DN2

Available on all sizes except

RIHN 30.
Required on Canadian

installation of

Model RIHN 60.

Protective Screen, Option DN3

This screen is designed to protect the

ceramic block from damage caused by

the entrance of foreign objects.

(

NOTE: Not for use with parabolic

reflector, Option DM2. If protective

screen is required with parabolic

reflector, contact factory.)

P/N 131793R10, Page 16
