17

Options

* Not available on LP Gas

1 All standard units fitted with unvented vent, natural gas and aluminized reflectors.
2 1 off 180° ‘U’bend or upto 2 off 90° ‘L’bends can be fitted at no less than 50% of the total heater length.
3 4” (101mm) or 6” (152mm) vent terminal.
4 Combustion air kit.
5 Reflector end caps.
6 Altitude conversion kit.
7 Propane and propane altitude conversion kit.

MODEL

U TUBE

STRAIGHT TUBE

U20

U40

U60

S20

S30

S40

S50

S60

S70

60

80

100

125

150

170

200

MODEL

TUBE TYPE MATERIAL

MIN DISTANCE

TO BEND

Calcoat™

Mild Steel

60

TUBE 1

REMAINDER

10 (3.1)

80

TUBE 1

REMAINDER

15 (4.6)

100

TUBE 1

REMAINDER

15 (4.6)

125

TUBE 1

REMAINDER

15 (4.6)

150

TUBE 1

REMAINDER

20 (6.1)

170

TUBE 1 & 2

REMAINDER

25 (7.6)

200

TUBE 1 & 2

REMAINDER

25 (7.6)

Technical Details continued
