13
Options * Not available on LP Gas
1 All standard units fitted with unvented vent, natural gas and aluminized reflectors.
2 1 off 180° ‘U’ bend or up to 2 off 90° ‘L’ bends can be fitted at no less than 50% of the total heater length.
3 5ft tube kit, 4” (101mm) or 6” (152mm) vent terminal.
4 Combustion air kit.
5 Reflector end caps.
6 Altitude conversion kit.
7 Propane and propane altitude conversion kit.
MODEL
U TUBE STRAIGHT TUBE
U20 U40 U60 S10 S20 S30 S40 S50 S60 S70
60 ● ● ● ● ●
80 ● ● ●
100 ● ● ●
125 ● ● ● ●
150 ● ● ● ● ●
170 ● ● ● ●
200 ● ● ● ●
MODEL
TUBE TYPE MATERIAL
MIN DISTANCE
TO BEND
Calcoat™ Mild Steel
60 TUBE 1 REMAINDER 10 (3.1)
80 TUBE 1 REMAINDER 15 (4.6)
100 TUBE 1 REMAINDER 15 (4.6)
125 TUBE 1 REMAINDER 15 (4.6)
150 TUBE 1 REMAINDER 20 (6.1)
170 TUBE 1 & 2 REMAINDER 25 (7.6)
200 TUBE 1 & 2 REMAINDER 25 (7.6)
Technical Details continued
