RED ROCKET-X INSTALLATION INSTRUCTIONS
955-0033, REV-B | 43
TECHNICAL DATA
CAUTION: The chassis of the computer system where the RED ROCKET-X is installed must be equipped with
sufficient ventilation to ensure proper cooling.
SPECIFICATION DESCRIPTION
PCI Bus Requirements PCIe slot that accepts a x16 card, and has 16 lanes of data
for maximum performance
One (1) 6-pin PCIe power cable
Board Size Full-length PCIe (approx. 12" length), single-slot
Operating Temperature Range 5°C to 40°C (41°F to 104°F)
Storage Temperature Range –17°C to 70°C (0°F to 158°F)
Operating Humidity Range 20% to 80%, non-condensing
Storage Humidity Range 10% to 80% relative humidity, non-condensing
HARDWARE SPECIFICATIONS
VIDEO OUTPUT
HDMI Dual Mode Display 2 DisplayPort
Serial Digital 4:2:2 8/10 bit (Single Link) 1 BNC
Serial Digital 4:4:4 8/10/12 bit (Dual Link) 2 BNC
AUDIO OUTPUT
Embedded Audio 1 BNC (Via Video Out)
TIMECODE OUTPUT
Vertical (VITC) 1 BNC (Via Video Out)
DATA FORMATS DESCRIPTION
Color Modes YCbCr 4:2:2 RGB 4:4:4
Internal Processing Real-time REDCODE decoding, debayering, and scaling
Audio Formats 48 kHz, 24 bit
A
TECHNICAL
SPECIFICATIONS
