38

ZA-42 Zone Adder Module

May be added to PFC-5004E.

4 supervised Class B (Style B) or 2 Class A (Style D) initiating circuits; confi gurable. [Compatibility ID “A”]
Power limited: 22VDC, 3 mA standby, 1.5Vp-p ripple, 50 mA max. (alarm)

2 Class B or A (Style Y or Z) NAC circuits; confi gurable as strobes or audibles.

Power limited: 24 VDC unfi ltered, 1.7A per Circuit

Current consumption:

standby: 45 mA
alarm: 120 mA

ARM-4/ARM-8 Relay Module

Four or eight relays: Form C, 1A (resistive), 28 VDC per
contacts

Each individual relay can be relay per zone, common alarm,
common supervisory

Current Consumption:standby: 5 mA
alarm: 160 mA

Polarity Reversal and City Tie Module (PR-5100)

Supervised city tie:not power limited

24VDC unfi ltered, 210 mA max., Trip coil: 14 ohms

Polarity reversal: power limited

24VDC open, 12VDC @ 3.5 mA, 8 mA max. (shorted)

Current consumption: standby: 35 mA
alarm: 300 mA

Miscellaneous

Remote Trouble Indicator (RTI-1)

Trouble LED and Buzzer

End-of-line resistor plates (MP-300, MP-300R).

Internal 3.9 Kohm, ½ Watt, 5% resistor.

Ground Fault Impedance = 13.5 Kohm

System model: PFC-5000 Fire Alarm Control Panel
System type: Local, auxiliary (using PR-5100), remote station protected premises (using UDACT-9100 or PR-5100), central station
protected premises (using UDACT-9100).
Type of service: A, M, WF, SS (SS is only local or with UDACT-9100)
Type of signalling: Non-Coded
Equipment standards: UL-864 - Rev.9, ULC S-527-99

Installation Standards: NFPA 70 and 72, ULC-S524, CEC Part-1 C22.1

Inspection and Testing Standard: ULC-S536
