Indicators, Controls, & Operation
Refer to Figure 17 below for LED Indicators and control switch locations.
Figure 17: Indicators and Control Location
Indicators
Buzzer
The buzzer is activated by any of the following:
Fire alarm: •
steady
Supervisory alarm: • fast fl ash rate of 120 beeps per minute
Trouble: • slow fl ash rate of 20 beeps per minute
If the buzzer turns on in response to a non-latching trouble or supervisory, it will be turned off if the condition causing it goes
away and there is no other reason for it to be on.
AC On LED
The green AC On LED illuminates steadily while the main AC power is within acceptable levels. It turns off when the level falls
below the power-fail threshold and the panel switches to standby (battery) power.
Common Alarm LED
The Common Alarm indicator turns on steady red whenever the panel is in alarm as a result of an alarm on any initiating circuit.
Since all alarms are latched until the panel is reset, the indicator will remain on until reset.
