29
Table 3: Confi guration DIP Switch Functions on Main Fire Alarm Board
Function DIP Switch Switch "Off" Switch "On"
NAC Circuit #1
Audible Device (Bell) Only Switch 13, #1 Silenceable Non-Silenceable
NAC Circuit #2
Audible or Visual Device Switch 13, #2 Silenceable Non-Silenceable
Switch 13, #3 Audible Device (Bell) Visual Device (Strobe)
# Remote Annunciators Switch 13, #4 5 off, 4 off = None 5 off, 4 on = One
5 on, 4 off = Two 5 on, 4 on = Three
Switch 13, #5
Manual Signal Silence Switch 13, #6 Disabled Enabled
Fire Dril Switch 13, #7 Disabled Enabled
Aux. Disconnect Switch 13, #8 Disabled Enabled
Initiating Circuit #1
Alarm Only Switch 11, #1 Normal Alarm Verifi ed Alarm
Initiating Circuit #2
Alarm Only Switch 11, #2 Normal Alarm Verifi ed Alarm
Initiating Circuit #3
Alarm or Waterfl ow Switch 11, #3 Normal Verifi ed Alarm / Retarded
Waterfl ow
Switch 11, #4 Alarm Waterfl ow
Initiating Circuit #4
Alarm or Supervisory Switch 11, #5 Normal Verifi ed Alarm (no effect on Supv.)
Switch 11, #6 Alarm Supervisory
Switch 11, #7 Non-Latching Supervisory
(No effect on Alarm) Latching Supervisory
(No effect on Alarm)
Application of AC Power Fail Delay Switch 11, #8 No AC Power Fail Delay Apply AC Power Fail Delay
Signal Code Switch 9, #1 2 off, 1 off = Temporal Code 2 off, 1 on = Continuous
2 on, 1 off = March Time 2 on, 1 on = California Code
Switch 9, #2
Zone Disc Switches Switch 9, #3 3 off = Disabled 3 on = Enabled
Auto Signal Silence Switch 9, #4 4 off = Disabled 4 on= 20 Minutes
Signal Silence Inhibit Switch 9, #5 None 1 Minute
Initiating Circuit Style / Class Switch 9, #6 Class B (Style B) Class A (Style D)
Aux. Devices Switch 9, #7 Non-Silenceable Silenceable
AC Power Fail Delay to
Aux. Devices Switch 9, #8 24 Hour Standby
Standard 60 Hour Standby
Standard
Note:
After you change any confi guration switches, perform a system hard reset or power off/on sequence. If this is not done,
•
then a Switch Tamper Trouble will occur. Perform a hard reset by pressing SW0 push button switch on back of main
panel pcb.
Do not use retard operation with any external retarding device; maximum retard may not exceed 90 seconds. •
