Service procedures – Novak Atom and Cyclone ESC User Manual
Page 28
28
CYCLONE & ATOM INSTRUCTION MANUAL
PLEASE NOTE: Speed controls that operate normally when
received will be charged a minimum service fee and return
shipping/handling costs.
Before sending in your speed control for service, it is important
that you review the Trouble-Shooting Guide and all
instructions. The speed control may appear to have failed
when other problems exist in the system such as a defect in
the transmitter, receiver or servo, incorrect adjustments/
installation.
•
If you have a Custom Profile installed on your speed
control, Novak recommends you make a copy of it
before sending your speed control in, as Novak cannot
guarantee that it will remain in the ESC after servicing.
•
Do not cut the input harness or switch harness off the
speed control before sending it in for service. Cut wires
must be replaced for testing purposes, and will be
charged the current service fees.
•
Hobby dealers or distributors are not authorized to
replace speed controls thought to be defective.
•
If a hobby dealer returns your speed control for service,
submit a completed SERVICE CARD to the dealer and
make sure it is included with the speed control.
•
Novak Electronics, Inc. does not make any electronic
components (transistors, resistors, etc.) available for sale.
SERVICE PROCEDURES
Continued
