Novak Atom and Cyclone ESC User Manual
Page 15
CYCLONE & ATOM INSTRUCTION MANUAL
15
STEP 4: Transmitter Adjustments (continued)
AIRTRONICS CL-3PS
FIRST: With the trigger in the brake position, set EPA/TH to 90%,
then adjust the TH-EPA-L knob to full counter-clockwise position.
EPA/TH
(F/B)
ARC-TH
REV-TH
TH-TRIM
140%/160%
0%
NOR
(Middle)
NOTE: After speed control set-up, the TH-EPA-L knob will be
used to reduce maximum push brake.
AIRTRONICS CS-2P
TH-EXPO EPA-HIGH
EPA-LOW
Rev.Switch TH-TRIM
NOR
(cw)
(cw)
(cw)
NOR
(Middle)
NOTE: After speed control set-up, the EPA-LOW pot will be
used to adjust maximum push brake.
AIRTRONICS M8
EPA-(BR/HI) EXP-(BR/HI) TRM(SUB)
REV
TRIM-TH
110%/125%
0%/0%
0
NORMAL
(Middle)
NOTE: After ESC set-up,TRIM-TH will be used to adjust coast
brake, and the “+ BRAKE –“ thumb-switch will be used to
reduce maximum push brake (do not go above 110% EPA-BR).
Continued
CW
Clockwise
CCW
Counter-Clockwise
F
Full throttle trigger position
B
Full brake trigger position
TRANSMITTER CHART ABBREVIATIONS
